C20DX Automatic Pyramids tea bag packaging machine

Application:

C20DX Automatic Pyramids tea bag packaging machine is suitable for tea packaging products such as loose leaf tea, herbal tea, health care tea, rose tea, ginseng and other Chinese kinds of local tea, etc.

Features:

1. The feasible package materials of the triangle bag machine is nylon, non-woven fabric materials imported from Japan, which is non-toxic, non-bacteria, heat-resistant, high-quality and food-grade, conforming to our national safety inspection standard.

2. The pyramid tea bag machine uses a unique sealing method - ultrasonic. It can seal tightly, safely, and reduce the width of the extra edge, avoiding any waste of packing materials.

Technical data:

Machine type: Tea Bag Packing Machine Series

Product model: C20DX

Product name: C20DX Automatic Pyramids tea bag packaging machine

Package materials: Nylon material imported from Japan, non-woven fabric, 100% biodegradable transparent materials, PET, PLA, etc

Measuring: Measuring cup filler

Filling range: 1-10g/bag, accuracy: ≤ ±0.2g/bag

Packing speed: 40~60 bags/min

Packing roll width: 140, 160, 180(mm)

Sealing length: 50, 60, 70, 80(mm)

Sealing method : sealing and cutting by ultrasonic

Qty of sealing device : 2 sets

Air supply: ≥0.6MPa(can be equipped with air compressor)

Motor power: 220V, 50HZ, 1.2KW

Dimension : 1200*900*2300mm(L*W*H)

Weight: 400KGS

Xiamen  Sengong  Packing  Equipment  Co.,  Ltd  was  established  in  2004.  It  is  an  in-novative  and  national  high-tech  enterprise.  Our  company  specializes  in  the  re-search  &   development,  manufacturing,  selling  and  servicing  of  itelligent  beveragepacking  machines(pyramid  bag,  drip  offee  bag  and  tea  bag,  etc).
We  have  a  very  strong  and  professional  ultrasonic  technology  team  and  seniorexperiences  of  production  management.  Our  products  have  obtained  a  greatnumber  of  national  practical  patents  and  invention  patents.  Sengong  is  also  cer-tified  by  ISO,  CE  which  ensures  the  safety  standard  for  all  users.  With  more  than
ten  years  ot  continuous  progress  In  technology,  we  have  created  a  series  ot  saterand  more  flexible,  stable  and  sanitary  equipment,  providing  advanced  packag-ing  solutions  for  global  customers.  And  our
machines  were  sold  all  over  the  world  including  the  USA,  the  UK,  Italy  ,Canada,Australia,  Russia,  Turkey,  and  so  on.
Sengong  owns  an  excellent  after  -sales  service  team  and  cloud  support  system(online).  With  more  than  ten  experienced  technicians,  engineers  and  senicr  ex-ecutives,  we  can  always  provide  high  quality,  fast  and  efficient  service  forall  customers.
