C20 Automatic Pyramid Nylon Tea Bag Packaging Machine

C20 Automatic Pyramid Nylon Tea Bag Packaging Machine

  • Item NO.:

    C20
  • Lead Time:

    30 business days after deposit arrived
  • Product Orgin:

    CHINA
  • Brand:

    SENGONG
  • Shipping Port:

    Xiamen port
  • Payment:

    BY T/T or L/C
  • Color:

    as picture
Product Details



 Application:

It is suitable for tea packing products such as loose leaf tea, herbal tea, health care tea, rose tea, ginseng and other Chinese kinds of local tea, etc.

 Features:
1. The feasible package materials of the triangle bag machine is nylon, non-woven fabric materials imported from Japan, which is non-toxic, non-bacteria, heat-resistant, high-quality and food-grade, conforming to our national safety inspection standard.
2. The machine uses a unique sealing method - ultrasonic. It can seal tightly, safely, and reduce the width of the extra edge, avoiding any waste of packing materials.

 Technical data

Machine type: Tea Bag Packing Machine Series
Product model: C20
Product name: Automatic Pyramid Nylon Tea Bag Packing Machine
Package materials: Nylon material imported from Japan, non-woven fabric, 100% biodegradable transparent materials, PET, PLA, etc
Measuring: Measuring cup filler
Filling range: 1-10g/bag, accuracy: ≤ ±0.2g/bag
Packing speed: 40~60 bags/min
Packing roll width: 140, 160, 180(mm)
Sealing length: 50, 60, 70, 80(mm)
 Sealing method : sealing and cutting by ultrasonic
 Qty of sealing device : 2 sets
Air supply: ≥0.6MPa(can be equipped with air compressor)
Motor power: 220V, 50HZ, 1.2KW
Dimension : 1200*900*1800mm(L*W*H)
Weight: 350KGS
